SF730 Series Vector control frequency inverter
Power Range:
Single Phase AC 220V-240V 0.4kW-7.5kW
Three Phase AC 220V-240V 0.4kW-160kW
Three Phase AC 340V-460V 0.75kW-450kW
Product Features:
SF730 series inverters have the following features:
1. Support mobile APP and Wi-Fi module to facilitate inverter debugging and monitoring.
2. Reliable operation withc full load at 50°C ambient temperature.
3. Integrated of special functions for rewinding and unwinding.
4. Support the high frequency output up to 3000Hz for driving high-speed motors.
5. Support 100kHz high-speed pulse input.
6. The built-in filter is close to level C3 , so the external interference is greatly reduced.
7. The metal substrate should adapt to the vibratory environ-ment to reduce the induced voltage of the motor.
Technical Specification:
Rated voltage of power supply | Model | Applicable motor power (kW) |
Heavy-duty rated output current (A) | Light-duty rated output current (A) |
Single-phase/three-phase AC 200V~240V |
SF730-0R4-2B | 0.4 | 2.8 | 3.2 |
SF730-0R7-2B | 0.75 | 4.8 | 5.0 | |
SF730-1R5-2B | 1.5 | 8 | 8.5 | |
SF730-2R2-2B | 2.2 | 10 | 11.5 | |
Three-phase AC 340~460V |
SF730-0R7-3B | 0.75 | 2.5 | 3 |
SF730-1R5-3B | 1.5 | 4.2 | 4.6 | |
SF730-2R2-3B | 2.2 | 5.6 | 6.5 | |
SF730-4R0-3B | 4.0 | 9.4 | 10.5 | |
SF730-5R5-3B | 5.5 | 13 | 15.7 | |
SF730-7R5-3B | 7.5 | 17 | 20.5 | |
SF730-011-3B | 11 | 25 | 28 | |
SF730-015-3B | 15 | 32 | 36 | |
SF730-018-3B | 18.5 | 38 | 41.5 | |
SF730-022-3B | 22 | 45 | 49 | |
SF730-030-3/3B | 30 | 60 | 70 | |
SF730-037-3/3B | 37 | 75 | 85 | |
SF730-045-3 | 45 | 90 | 105 | |
SF730-055-3 | 55 | 110 | 134 | |
SF730-075-3 | 75 | 150 | 168 | |
SF730-090-3 | 90 | 176 | 200 | |
SF730-110-3 | 110 | 210 | 235 | |
SF730-132-3 | 132 | 253 | 290 | |
SF730-160-3 | 160 | 304 | 340 |
Item | Specification | |
Power supply | Rated voltage of power supply | Three-phase 340V-10% to 460V+10%, Single-phase/three-phase 200V-10% to 240V+10%; 50-60Hz ± 5%; voltage unbalance rate: <3% |
Output | Maximum output voltage | The maximum output voltage is the same as the input power voltage. |
Rated output current | Continuous output of 100% rated current | |
Maximum overload current | 150% heavy-duty rated current: 60s; 180% heavy-duty rated current: 10s; 200% heavy-duty rated current: 2s 120% light-duty rated current: 60s; 150% light-duty rated current: 10s; 180% light-duty rated current: 2s |
|
Basic control functions | Drive mode | V/F control (VVF); speed sensorless vector control (SVC) |
Input mode | Frequency (speed) input, torque input | |
Start and stop control mode | Keyboard, control terminal (two-line control and three-line control), communication | |
Frequency control range | 0.00~600.00Hz/0.0~3000.0HZ | |
Input frequency resolution | Digital input: 0.01Hz/0.1Hz Analog input: 0.1% of maximum frequency |
|
Speed control range | 1:50 (VVF), 1:200 (SVC) | |
Speed control accuracy | Rated synchronous speed ± 0.2% | |
Acceleration and deceleration time | 0.01 s to 600.00 s / 0.1 s to 6,000.0 s / 1 s to 60,000 s | |
Voltage/frequency characteristics | Rated output voltage: 20% to 100%, adjustable Reference frequency: 1Hz to 600Hz/3,000Hz |
|
Torque boost | Fixed torque boost curve Any V/F curve is acceptable. |
|
Starting torque | 150%/1Hz (VVF) 150%/0.25Hz (SVC) |
|
Torque control accuracy | ±5% rated torque (SVC) | |
Self-adjustment of output voltage | When the input voltage changes, the output voltage will basically remain unchanged. | |
Automatic current limit | Output current is automatically limited to avoid frequent overcurrent trips. | |
DC braking | Braking frequency: 0.01 to maximum frequency Braking time: 0~30S Braking current: 0% to 150% rated current |
|
Signal input source | Communication, multi-speed, analog, etc. | |
Input and output function | Reference power supply | 10V/20mA |
Terminal control power | 24V/100mA | |
Digital input terminal | 5-channel digital multi-function input: X1~X5 X5 can be used as the high-speed pulse input (max. 100kHZ). |
|
Analog input terminal | 2-channel analog inputs: One (AI1) voltage source: -10 to 10V input; One channel (AI2): 0 to 10V input voltage or 0 to 20mA input current optional; |
|
Digital output terminal | Multi-function output of one open collector and one relay Maximum output current of the collector: 50 mA; Relay contact capacity: 250VAC/3A or 30VDC/1A, EA-EC: normally open; EB-EC: normally closed |
|
Analog output terminal | One multi-function analog terminal output M1: 0-10V/0-20mA multi-function analog output terminal |
|
Keyboard | LED display | The LED digital tube displays relevant information about the inverter. |
Protection | Protective Function | Short circuit, overcurrent, overvoltage, undervoltage, phase loss, overload, overheat, load loss, external protection, etc. |
Use conditions | Location | Indoor, at an altitude of less than 1 km, free of dust, corrosive gases and direct sunlight. When the altitude is higher than 1km, it is derated by 1% per 100m. The maximum allowable altitude is 3km. |
Applicable environment | -10℃ to +50℃, 5% to 95%RH (no condensation). When the ambient temperature exceeds 50°C, it needs to be derated by 3% per 1°C temperature rise. The maximum allowable ambient temperature is 60°C. | |
Vibration | Less than 0.5g | |
Storage environment | -40℃~+70℃ | |
Installation method | Wall-mounted or installed in the cabinet | |
Levels of protection | IP20/IP21 (with plastic baffle) | |
Cooling method | Forced air cooling |
